APPLICATION: These cables are used in high rise buildings. commercial complexes, schools and educational institutions. hospitals, etc. for the connection With security systems like smoke detectors, emergency lightings, exit signboards and fire command center. These cables are used where the fire safety is utmost important.
| Technical Data : | -40oC to +90oC |
| Rated Voltage : | 300/500V |
| Specifications : | BS 7629-1, BS EN 50200 |
| Range : | 2c-4c x 1.5-2.5mm2 |
| Insulation Available : | High performance fire resistant silicone rubber |
| Overall Screen : | AUPET (Aluminium/Polyester Tape |
| Circuit Protective : | Tinned Copper |
| Outer Sheath : | LSZH (Low Smoke Zero Halogen) |
| Cross Sectional Area of Conductor (Nom.) | Overall Dia (App.) for Cross Sectional Area of Conductor | ||
|---|---|---|---|
| 2 Core | 3 Core | 4 Core | |
| (Sq mm) | (mm) | (mm) | (mm) |
| 1.5 | 10.0 | 10.8 | 12.0 |
| 2.5 | 11.5 | 12.3 | 13.5 |
